Motor Model | Rated Voltage | KV Rating | Duty Cycle (Continuous Operating Time) | Weight （KG） | Rated Current （A） | Temperature （℃） | Thrust Efficiency （g/W） | Axial Thrust （KG） | Propeller （incn） |
XT3526 | 24V | 345KV | S3-40% | / | 22.4A | / | / | / | / |
Voltage | Propeller | Throttle(%) | Current(A) | Speed(RPM) | Thrust(kg) | Torque(N.m) | Power Input(W) | Power Output(W) | Efficiency(g/W) |
| 24V | / | / | 1.7 | 8280 | / | 8.6 | 40.8 | 7.5 | / |
/ | 5.1 | 8000 | / | 95.6 | 122.4 | 80.1 | / | ||
/ | 7.46 | 7750 | / | 165.3 | 179.0 | 134.1 | / | ||
/ | 10.2 | 7500 | / | 243.6 | 244.8 | 191.3 | / | ||
/ | 13.3 | 7250 | / | 342.1 | 319.2 | 259.7 | / | ||
/ | 16.3 | 7000 | / | 439.8 | 391.2 | 322.4 | / | ||
/ | 18.9 | 6750 | / | 521.3 | 453.6 | 368.5 | / | ||
/ | 21.1 | 6500 | / | 598.5 | 506.4 | 407.4 | / | ||
/ | 22.4 | 6400 | / | 638.9 | 537.6 | 428.2 | / | ||
/ | 23.8 | 6250 | / | 687.1 | 571.2 | 449.7 | / | ||
/ | 26.2 | 3960 | / | 773.2 | 628.8 | 485.8 | / | ||
/ | 29.8 | 5750 | / | 877.4 | 715.2 | 528.3 | / | ||
| / | 33.8 | 5500 | / | 987.9 | 811.2 | 568.9 | / |
