Motor Model | Rated Voltage | KV Rating | Max.Thrust Force | Weight （KG） | Rated Current （A） | Temperature （℃） | Thrust Efficiency （g/W） | Axial Thrust （KG） | Propeller （incn） |
XT3115 | 25.2V | 900KV | 4.07KG | / | 17.5A | / | 4.36-5.37 | 1.25-1.83KG | 10 |
Voltage | Propeller | Throttle(%) | Current(A) | Speed(RPM) | Thrust(kg) | Torque(N.m) | Power(W) | Efficiency(g/W) |
| 25.2V | 1050-3 | 10% | 0.4 | 1822 | 0.52 | / | 8.9 | 5.82 |
20% | 1.2 | 3603 | 0.21 | / | 29.4 | 7.07 | ||
30% | 2.78 | 5126 | 0.46 | / | 66.6 | 6.93 | ||
40% | 5.35 | 6608 | 0.80 | / | 128.2 | 6.27 | ||
50% | 9.68 | 8114 | 1.25 | / | 231.9 | 5.37 | ||
60% | 17.55 | 9811 | 1.83 | / | 419.5 | 4.36 | ||
70% | 25.9 | 11100 | 2.37 | / | 617.5 | 3.84 | ||
80% | 37.24 | 12387 | 2.99 | / | 884.9 | 3.37 | ||
90% | 50.08 | 13413 | 3.55 | / | 1185.9 | 2.99 | ||
| 100% | 64.66 | 14221 | 4.07 | / | 1526.5 | 2.66 |
