Motor Model | Rated Voltage | KV Rating | Max.Thrust Force | Weight （KG） | Rated Current （A） | Temperature （℃） | Thrust Efficiency （g/W） | Axial Thrust （KG） | Propeller （incn） |
M13 | 70V | 45KV | 58.8KG | / | 43A | / | 8.4-7.7 | 25-27KG | 56*20 |
Voltage | Propeller | Throttle(%) | Current(A) | Speed(RPM) | Thrust(kg) | Torque(N.m) | Power Input(W) | Power Output(W) | Efficiency(g/W) |
| 70V/18S | 5620 | 30% | 10.9 | 1004 | 9.5 | 6.3 | 763.0 | 662.4 | 12.5 |
35% | 12.7 | 1061 | 10.7 | 7.0 | 889.0 | 777.8 | 12.0 | ||
40% | 17.2 | 1183 | 13.3 | 8.7 | 1204.0 | 1077.8 | 11.0 | ||
45% | 26.0 | 1364 | 17.8 | 11.4 | 1820.0 | 1628.4 | 9.8 | ||
50% | 36.9 | 1532 | 22.7 | 14.3 | 2583.0 | 2294.2 | 8.8 | ||
55% | 43.5 | 1704 | 25.5 | 16.0 | 3045.0 | 2855.2 | 8.4 | ||
60% | 56.6 | 1762 | 30.4 | 18.9 | 3962.0 | 3487.5 | 7.7 | ||
65% | 71.7 | 1889 | 35.52 | 22.0 | 5019.0 | 4352.1 | 7.1 | ||
70% | 82.2 | 2000 | 39.0 | 24.2 | 5754.0 | 5068.6 | 6.8 | ||
75% | 101.4 | 2119 | 44.5 | 27.5 | 7098.0 | 6102.5 | 6.3 | ||
80% | 122.3 | 2248 | 49.6 | 30.6 | 8561.0 | 7203.8 | 5.8 | ||
85% | 135.8 | 2328 | 53.3 | 32.85 | 9506.0 | 8008.7 | 5.6 | ||
90% | 153.0 | 2400 | 57.0 | 35.3 | 10710.0 | 8872.1 | 5.3 | ||
100% | 161.8 | 2435 | 58.8 | 36.2 | 11326.0 | 9231.0 | 5.2 |
